Ship’s Log / “Revanche II” 07/06/2014
Hull #HATCN753H586 Doc #693418
Propulsion - Detroit Diesel 6 V 92 TA @ 450 HP
Model#...Port 80623401 Stbd 80627401
Serial#....Port 6VF118727 Stbd 6VF119123
Raw Water Impeller:Jabsco 17936-0001 Turbos (4) 5106250 (DD#)
Garret T04B98
Generator – Onan MDL4 20 KW (diesel power L423D – M)
Start , stop, preheat switch Sam’s part #24155, Onan #S11
Filters
AC Napa Fleetrite Luberfiner Fram
Propulsion: 8V92TA GM
Air (Walker conical) CD190 Port Supply 6888895 7 ½ X 10”
Fuel
Primary TP540X 3540
Secondary
Racor (2020SM) 3212
Oil
PF911D 1970 LFP 911 PH3612
Trans Oil
Generator: Onan MDL4 20 KW
Model: 3CR/25804A, Serial: B 840697660, Standby 60HZ, 1800RPM
Transformer: Nicollet Technologies Corp, Minneapolis, Mn 55413, NTI 1273, 31505525, 9328
Pressure Cap (heat exchanger)
Fuel
Primary 3130 7/2015 replace w inline #3032
Secondary
Racor (2010SM) PF147 1138 (5/18, Racor store 2040N-10(microns))
Oil 1592
Raw Water Pump: Sherwood K76B, SN 06248
Starter Motor Onan, 191-1550, 24 Volt
Turbo to Exhaust Clamp #513434 (Marine Exhaust Systems CL418)
Blower Motor - Jabsco (Par) 35900-0020 32V
G.E. Electrical Bulbs - Instrument lites and misc. #1828 .05W, 1822 .1W
Nav Lites – Perko232947,232939 (109G,R) Bulbs 0070DP2CLR 32V,12W,.4Amps
Perko basket strainer #049300699D Stainless 2 5/8” X 5 7/8”, head intakes
#049300799D Stainless 2 5/8 X 6 ¼ ,AC intake
Onan 20 KW Diesel L423D-M; Raw water pump – 132-0275, Sherwood K75B
Marina Jack Dockmaster 955-9488
Otmar’s Onan Generator 366-2470
Sam’s Marine, Ft Lauderdale 954 585 8933
Watermaker: Village Marine Tec (villagemarine.com) SPW 400 Serial 5053
Ft. Lauderdale (954) 523-4900 Henry
Main Membrane $250 Ea. 08/2004; Filters, Membranes; Wateranywhere.com
Plow Anchor 65’ AAA chain w/ 200’ 3 strand nylon
Danforth 65’ AAA chain w/ 200’ 3 strand nylon
Air Conditioner Circuit Boards Mother A281C Panel SMX 28 B
Filters: Fwd Strm 10 X 10
Galley 18 X 06
VIP 14 X 06
Mstr Strm 18 X 05
Pilot Hse 15 X 03
Saloon 12 X 12
Dingy windlass switch: Kraus & Naimer CA20 C54050 Z ANSL90029/001 0411
Yahama 15 HP 4 stroke F15ESHY Carb 66M 14301-12
66 M 201310, Spark plugs: NGK 7912 D7EA (Depco)
Oil Change Pump Reverso OP4 32V, ID85040; impellor #360010
30” Drawer refrigerator, Marvel Model 8 ORD 701; Serial 200903004052H
Radar Clearance 21’ 11
A/C Pump; Oberdorfer 109 MB JL9 Dayton 6K580, seal kit OB10721
Dual 20 AMP Circuit Breaker, Airpax Dual Pole, Issue LL9447,239,27050,WIH69Y
Capacities: Lbs. 05 10 15 20 25
Rear Tank 75 150 225 300 325
Fwd Tank 80 160 240 320 400
Fwd Water 36 72 108 144
Rear Water 47 94 141 188
Motors:
Propulsion 2 Generator 1 Bilge 4
Sump 2 Exhaust Fans 4 A/C 4
A/C Pump 1 Head 3 Fresh Water 1 (37)
Compressor 7 Windless 1 Auto Pilot 1
Radar 1 Outboard 1 Davit 1
Spotlite 1 Oil Change 2
Cables: Hatteras Specs 1-18’, 2-20’, 1-26’, 4-22’, 2-28’
Port Throttle Upper Station: DP-33C-28 Diesel Pro, 28’
Port Throttle Lower Station: 22’
Port Shift Upper: 28’?
Port Shift Lower: 26’?
Stbd Throttle Upper: (sync) 22’
Stbd Throttle Lower (sync) 22’
Stbd Shift Upper Station: TEL-CC23022 TELEFLEX CONTROL CABLE 3300 22'
Stbd Shift Lower Station: TEL-CC23020 TELEFLEX CONTROL CABLE 3300 20
Port Shut down: 18’? Stbd Shut down: 20’?
Shoreline fuse holders (two per socket, source one, source two, port side “A”, stbd side “B”)
FIC model 5900-11
Zincs, Shaft “, Rudder 5”(R4)
Arch Lites, Hampton Bay 240 236
Head Intake Hose 2 3/8” X 5’
Rope Lites 84’
Whaler seat 47” X 11”, Fwd cover 23 1/8” X 12” X 23 3/8”
