Electrical System
- High quality DC electrical switch panel with circuit breakers, LED indicator lights and voltage display
- Marine grade tinned electrical wiring with extensive use of heat sealed connectors
- Batteries x 3 comprising: House System (260 amp hrs) : 2 x 130 amp hr heavy duty batteries. One engine cranking battery – 130 amp hr heavy duty battery
- 230amp heavy duty isolation switch
- 12 V lighting : Numerous 12V interior lamps and courtesy lights throughout including recessed lights in cockpit
- 4 x 12V Outlets
- CE approved navigation lights. Port & Starboard mounted on bow rails
- Deck floodlight mounted on spreaders
- Mast head anchor / riding light
Deck
- Aluminium Hatches & portholes (9 in total)
- 4 x Forward Hatches, 2x mid cabin hatches, 1x port bathroom hatch, 1x galley hatch, 1x aft cabin hatch
- Fibreglass Deck Hatches: 5 x Forward anchor & storage hatches. 2 x Cockpit engine access hatches.
- 6 x Docking cleats. Each side : bow, stern & amidships
- 6x Safety handles around cockpit
- 1 x Heavy duty mooring cleat on forward walkway
- Ventilation: 2 x forward cabin hatch vents
- Mast base turning blocks. All halyards & sail controls to cockpit
- 9 x Rope clutches
- Sheet winches : 1 x 45ST – 2 speed self tailing, 2 x 40ST – 2 speed self tailing
- Stanchions/Rails: High quality stanchions, bow rails and stern rails with 3 life-lines
- 2 x transom access gates with pelican hook releases
- 2 x side access gates with pelican hook releases
- Aft swim ladder: folding stainless aft swim ladder
Rigging
- Clear anodised aluminium mast and boom. Single Spreader, 7/8 rig
- Standing Rigging: – Forestay 3/8 (10mm) 1 x 19 Dieform wire – Sidestays 3/8 (10mm) 1 x 19 Dieform wire – Diamonds 5/16 (8mm) 1 x 19 Stainless Steel wire
- Halyards: – Main halyard: 12mm Spectra rope : Heavy duty shackle – Jib halyard: 8mm Spectra rope Heavy duty shackle. – Topping lift: 8mm rope Heavy duty shackle – Boom outhaul: 10mm Spectra
- Single line reefing, run to helm. Three reefing points with 2 reef lines: – Reef 1&3: 10mm rope Leech/Clew blocks and snap shackle – Reef 2: 10mm rope Heavy duty shackle
- Sheets: – Main sheet: 10mm rope – Main traveller control: 10mm rope – Jib sheet: 10mm rope
- All halyards, reefing lines to be lead back to cockpit through turning blocks, rope clutches
- Fully battened mainsail. Triple stitched reinforced construction. Leach adjustable batten end caps. Fibreglass sail battens.
- Mainsail cover with integrated lazy jack system
- Self-tacking headsail, curved headsail traveller track with end stops. With New single line control sheet to cockpit
Accomodations
- INTERIOR FINISH: New Lightweight interior redesign. Furniture and cabin sides gloss gelcoat finish. Cabin top lined with light weight internally molded gelcoat liner. New Floors: synthetic timber flooring. New Lightweight cupboard doors and trimmings
- SALOON: New Lightweight grp saloon table. Upholstered settee. New Lightweight grp coffee table. aluminium opening windows. Saloon side windows in 8mm toughened glass. Tri folding cockpit doors. Removable low profile, helm hatches.
- SLEEPING CABINS: Light weight pvc foam cored timber doors on all private cabins. Port & Starboard fwd cabins: Each queen sized bed (2050mm x 1540mm). Aft Starboard cabin: Double bed (1990mm x 1230mm). Mattresses 150mm ( 6” ) foam upholstered.
- PORT HEAD: Polished light weight pvc foam cored timber door. Polished light weight pvc foam cored timber door. Manual toilet. Discharge via holding tank.
- GALLEY: Spacious galley with co-ordinated Polystone counter surfaces. Three (3) burner LPG stove, stainless steel pot holders. Double bowl stainless steel sink. Front opening fridge 80 litres.
