2026 Beneteau Oceanis 51.1 | 52ft

 CONSTRUCTION

• Design made following European Directive requirements and according to CE certification
• Vacuum infused hull (GRP / Sandwich balsa wood)
• Vacuum infused structural inner liner (Fabric-resin) bonded to the hull
• lnjected deck construction in fiberglass and Saerform foam sandwich, covered with non-slip diamond pattern
• Cast iron keel fixed with bolts and stainless steel backing plates
• Twin rudders affixed with stainless steel stock
• White hull - Grey metal hull decoration
• 8 Hull portlights

DECK EQUIPMENT

RIGGING

• Anodized aluminum mast, deck stepped within - mast furling system, 2 Aft swept spreaders
• Anodized aluminum boom
• Discontinuous stainless steel standing rigging
• Split backstay
• Rigid boom vang
• Self - tacking jib with on - deck furler
• 2 Stand Up mainsheet blocks on the coachroof
• 1 Self-tacking jib track with traveller
• All lines lead back to the helm stations (except boom topping lift and genoa halyard)
• Complete running rigging: Main halyard, Genoa halyard with tensionning track on the mast, Boom topping lift with cleaton mast, Mainsheet, 1 Self-tacking jib sheet
• 6Clutches
• Halyard covers
• 2 Flag halyards

WINCHES

• 1 Self tailing winch (H46.2 STA) at each helm station
• 1 Aluminum Speed Grip winch handle
• 2 Winch handle holders

 SAILS

• Dacron furling mainsail with Natural UV protection
• Dacron self-tacking jib with Natural UV protection

MOORING - ANCHORING GEAR

• Self-draining chain locker - Clench bolt - Hatch cover
• Single roller stainless steel bow fitting with offset roller
• 12 V - 1 500 W vertical electric windlass - Remote control
• 6 Aluminum mooring cleats, Length: 400mm / 15’’3/4 - Stainless steel chafing plate

OWNER'S CABIN

Headroom: 1,95 m / 6’5’’

• Central double bed (2,05 m x 1,60 m x 1, 23 m /6’9’’x5’3’’x4’) lsland bed type, mounted on gas struts
• 2 Hanging lockers, Open storage compartment along the hull,

6 Upper lockers, 1 Storage space under bed (Drawer under the bed + Central stowage under bed)

• 1 Seat on both sides of the bed
• 2 Bedside tables with seat
• 2 Reading lights
• 2 USB sockets
• 1 Low shoe storage unit, 1 Mirror on bulkhead
• Stowage provided under the floor (Stowage for bottles + 2 2plastic baskets)

Piston - assisted hinges opening mechanism

• 2 Flush deck hatches with mosquito screen / blind
• 2 Hull portholes with sliding blind

2 PRIVATE HEADS:

Headroom: 1,85 m /6’1’’

to port:

• Manual marinetoilet
• 1 80 L / 21 US Gal Rigid holding tank
• White polyester basin built into the Corian Clay counter - top, Mixer tap
• 1 Cabinet - Mirror
• Toilet accessories
• 1 Deck hatch with mosquito screen / blind

to starboard:

• Shower with wooden seat, white polyester shower base
• 2 Storage closets
• 1 Deck hatch with mosquito screen / blind

PORT AFT CABIN

Headroom: 1,97 m / 6’6’’

• 1 Double bed (2,10 m x 1,60 m / 6’11’’ x5’3’’)
• 2 Hanging lockers - 1 Cupboard - Closed cubby holes
• 1 Bed access sideboard
• 2 Flexible and multi-directional reading lights at headboard
• 1 USB socket
• 1 Hull porthole with sliding blind
• 1 Cockpit opening window with curtain under cock pit seats
• 1 Fixed cockpit window with curtain on the coaming

STARBOARD AFT CABIN

Headroom: 1,97 m / 6’6’’

• 1 Double bed (2,10 m x 1,60 m / 6’11’’ x 5’3’’)
• 1 Hanging locker - 1 Cupboard - Closed cubby holes
• 1 Bed access sideboard
• 2 Flexible and multi-directional reading lights at head board
• 1 USB socket
• Access door to aft head
• 1 Hull porthole with sliding blind
• 1 Cockpit opening window with curtain under cockpit seats
• 1 Fixed cockpit window with curtain on the coaming

OWNER'S HEAD - STARBOARD

Headroom: 1,83 m / 6’

• Access from the salon or the starboard aft cabin
• Separate shower - 1 Mixer tap - White polyester shower base
• Corian Clay counter-top with self - draining storage
• 1 Manual marinetoilet
• 1 80 L / 21 US Gal Rigid holdingtank
• Washbasin - 1 Mixer tap
• 1 Cabinet + Storage space under the basin
• 2 Mirrors
• Toilet accessories
• 1 Opening port light with curtains in the coachroof side window

3  cabins 3 heads version

The pantry goes to the starboard side and is replaced by a head.

The aft cabins are symmetrical.

The port and starboard aft heads are symmetrical:

• Access from the salon or the aft cabin
• 1 Shower area accessible by swivelling the wash basin
• 1 Manual marine toilet
• 1 80 L / 21 US Gal Rigid holding tank
• 2 Mirrors
• Toilet accessories
• 1 Opening port light with curtains in the coach roof side window
• at base of companion way
• standard : 1 Hanging locker, Cupboard
• Place for washing machine (optional) instead of high unit
• Place for wine cellar or negative cold conservator, 1 drawer (optional) instead of the low cupboard

PANTRY - STARBOARD

4  cabins 2 heads version

The starboard head of the standard version is replaced by a cabin with bunk beds.

• Headroom: 1,83 m / 6’
• 2 Bunk beds: Top bunk (1,95 m x 0,79 m - 0, 54 m / 6’ 5’’ x 2’ 7’’ - 1’ 9’’) -Bottom bunk (1, 93 m x 0, 60 m - 0, 43 m / 6’ 4’’ x 2’ - 1’ 5’’)
• Storage
• 1 Opening porthole with curtain

4  cabins 4 heads version

The salon is unchanged. The cabins and heads are identical to version 3 cabins, 3 heads.

Forward: 2 cabins each with their private head.

5  cabins 3 heads version

 The starboard head of the standard version is replaced by a cabin with bunk beds:

• Headroom: 1,83 m /6’
• 2 Bunk beds: Top bunk (1, 95 m x 0, 79 m - 0, 54 m / 6’ 5’’ x 2’ 7’’ - 1’9’’) - Bottom bunk (1, 93 m x 0, 60 m - 0, 43 m / 6’ 4’’ x 2’ - 1’ 5’’)
• Storage
• 1 Opening porthole with curtain

2 SYMMETRICAL FORWARD CABINS

Headroom: 1,93 m / 6’4’’

• 1 Double bed (2 m x 1,36 m x 1,16 m / 6’7’’ x 4’6’’ x3’10’’)
• 1 Hanging locker - 2 Closed high shelves, 1 Open shelving
• 1 Drawer under the bed
• 2 Swivelling reading lights
• 1 Deck hatch with mosquito screen / blind
• 1 Hull porthole with sliding blind
• 1 USB socket
• Access door to the head

ENGINE

• Engine Yanmar Diesel:

-  80 HP/80 HP, Sail Drive, Common Rail (standard)

-  80 HP/80 HP, Common Rail, Dock & Go (Option)

-  110 HP/110 HP, Propeller shaft, Common Rail (Option)

• Engine throttle and control panel on starboard
• Engine compartment: Soundproofing foam - Ventilation: 3 air intakes and 1 forced air outlets
• 1 Alternator 12 V / 125Amp
• 1 Rotomolded diesel tank 200 L / 53 US Gal (under starboard aft berth) -Electronic gauge - Low level alarm - 1 Tank filling access
• Filters: Sea water - Diesel - Water separator
• Fixed three blade propeller
• 1 Engine access through companionway ( opening with 2 gas pistons) - 2 Engine access through aft cabins

ELECTRICITY

• 12 V Circuit
• 2 Service batteries (140 Amp) - 1 Engine battery (120 Amp)
• 1 Load balancer
• 12 V Electrical panel (Fuses - Voltmeter - Water gauge - Fuel gauge -Battery warning - Fuel warning - Water warning)
• 6 115 V Sockets
• 6 USB sockets
• 1 Shore power socket (115V)
• LED lighting: Overhead lights - Reading lights - Reading light, flexible and multi-directional
• LED navigation lights: 1 Masthead light - 1 Steaming light - 1 Mooring light on masthead
• Wire runs for optional cables

PLUMBING

• 1 Rotomolded fresh water tank 400 L / 106 US Gal, under berth in forward cabin - 1 Tank filling access
• Water pressure system - Expansion tank - lnline filter
• 40 L / 11 US Gal Electric water heater (engine use)
• 1 Rigid 80 L / 21 US Gal black water holding tank for eachWC
• Electrical shower drain pumps
• 1 Electric bilge pump
• 1 Manual bilge pump
• 1 Electric pump for the ice box drain

GAS

• 1 Box for 2 gas bottles in the cockpit (diameter: 0,28 m/ 11’’ x Height: 0,44 m/1’5’’)
• Regulator and solonoid
• Gas leak detector

MISCELLANEOUS ITEMS

• Smoke detector
